Cisco Catalyst 4507R-E Switch

The 7-slot Cisco Catalyst 4507R-E chassis are ideal for Power over Ethernet (PoE) or non-PoE enterprise wiring closets, and small distribution, small core, and branch offices that require the highest level of resiliency. The Cisco Catalyst 4507R-E supports redundant supervisors to minimize downtime. These chassis support all Cisco Catalyst 4500 Series classic and E-Series line cards.

Cisco Catalyst 4507R-E Switch Video Data Sheet

Video Data Sheet

The Catalyst 4507R-E is ideal for high availability wiring closet and small campus and branch aggregation deployments. (3:20 min)

Viewing this embedded video requires the latest version of Adobe Flash Player with JavaScript enabled.
Get the Flash Player

Cisco Catalyst 4507R-E Chassis Features
Total Number of Slots	7
Supervisor Engine Slots	2¹
Line Card Slot Speed	24Gbps and 6Gbps
Supervisor Engine Redundancy	Supervisor Engine 6-E, 6L-E, V-10GE, V, IV, II-Plus-10GE, II-Plus
Supervisor Engines Supported	Supervisor Engine 6-E, 6L-E, V-10GE, V, IV, II-Plus-10GE, II-Plus
Line Card Slots	5¹
Line Card Supports	E-Series and Classic³
Number of Power Supply Bays	2
AC/DC Input Power	Yes
Integrated PoE	Yes
Minimum Number of Power Supplies	1

¹ Slots 3 and 4 are for supervisor engines only.
² You can mount chassis in racks and cabinets that meet ANSI/EIA-310-D and ETS 300 119-3.
³ Classic line cards are all non-E-Series line cards.
